| CARACTERÍSTICAS DE HARDWARE |
| Interface | PCI Express(x1) |
| Dimensiones (An x Pr x Al) | 4.8 x 3.1 x 0.8in. (120.8 x 78.5 x 21.5mm) |
| Tipo de Antena | Detachable Omni Directional (RP-SMA) |
| Ganancia de la Antena | 2dBi |
| CARACTERÍSTICAS INALÁMBRICAS |
| Estándares inalámbricos | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frecuencia | 2.400-2.4835GHz |
| Tasa de señal | 11n: Up to 300Mbps(dynamic) |
| 11g: Up to 54Mbps(dynamic) |
| 11b: Up to 11Mbps(dynamic) |
| Sensibilidad de recepción | 270M: -68dBm@10% PER |
| 130M: -68dBm@10% PER |
| 108M: -73dBm@10% PER |
| 54M: -73dBm@10% PER |
| 11M: -89dBm@8% PER |
| 6M: -87dBm@10% PER |
| 1M: -90dBm@8% PER |
| Potencia de Transmision | <20dBm(EIRP) |
| Modos inalámbricos | Ad-Hoc / Infrastructure mode |
| Seguridad inalámbrica | Support 64/128 bit WEP, WPA-PSK/WPA2-PSK |
| Tecnología de modulación | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
| OTROS |
| Certificación | CE, FCC, RoHS |
| contenidos del paquete | Wireless Adapter |
| 2x Detachable Omni directional antenna |
| Resource CD |
| Quick Installation Guide |
| Requisitos del sistema | Windows 10/8.1/8/7，Linux |
| Ambiente | Operating Temperature: 0℃~40℃ (32℉~104℉) |
| Storage Temperature: -40℃~70℃ (-40℉~158℉) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
