| CARACTERÍSTICAS DE HARDWARE |
| Estándares y Protocolos | IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS |
| Interface | 1 Fixed Ethernet WAN Port |
| 1 Fixed Ethernet LAN Port |
| 3 Changeable Ethernet WAN/LAN Ports |
| Medios de Red | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) |
| 100BASE-TX: UTP category 5, 5e cable (Max 100m) |
| Botón | Reset Button |
| Fuente de Alimentación | Internal Universal Power Supply |
| AC100-240V~50/60Hz input |
| Flash | 8MB |
| DRAM | 64MB |
| LED | PWR, SYS, WAN, LAN, WAN/LAN |
| Dimensiones (W X D X H) | 11.6*7.1*1.7in. (294*180*44mm) |
| 13-inch Standard Rack-Mount Width, 1U Height |
| RENDIMIENTO |
| Sesiones Concurrentes | 30000 |
| FUNCIONES BÁSICAS |
| WAN Connection Type | Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable |
| MAC Clone | Modify WAN/LAN MAC Address |
| DHCP | DHCP Server/Client, DHCP Address Reservation |
| Configuración Switch | Port Mirror, Rate Control, Port Configuration, Port VLAN |
| FUNCIONES AVANZADAS |
| ACL | IP/MAC/URL/WEB Filtering |
| IGMP | IGMP Proxy/IGMP Snooping |
| Forwarding | Virtual Server, Port Triggering, DMZ |
| Equilibrio de carga | Policy Routing, Link Backup |
| NAT | One-to-One NAT, Multi-Nets NAT |
| Routing | Static Routing |
| Seguridad | FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death |
| Control de Trafico | Bandwidth Control, Session Limit |
| ADMINISTRACIÓN |
| Servicio | PPPoE Server, E-Bulletin, Dynamic DNS, UPnP, App Control |
| Mantenimiento | Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics |
| OTROS |
| Certificacion | CE, FCC, RoHS |
| Contenidos del Paquete | TL-R480T+ |
| Power Cord |
| RJ-45 Ethernet Cable |
| Installation Guide |
| Resource CD |
| Requisitos del Sistema | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux |
| Ambiente | Operating Temperature: 0℃~40℃ (32℉~104℉) |
| Storage Temperature: -40℃~70℃ (-40℉~158℉) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
